Tano Cable: Professional ABC cable manufacturer from China. Meet your various requirements for ABC wire and cable. Over 26 years  experience in overhead cable production and aluminum ABC cable export, overhead cables factory directly prices without third party. Emai: info@tanocable.com

Our advantage:
The location of our factory is the gathering place of aluminum cables in China, and even the core area of global aluminum cable procurement. The mature industrial chain gives us an absolute advantage in the supply of aluminum cables. Emai: info@tanocable.com

Custom Service:
Tano Cable can customize all different ABC aerial cable size, have a chat now, leave your messages. Emai: info@tanocable.com

Please kindly send us your inquiry aerial bunched cable list and order quantity, our sale managers will reply you as soon as possible.Emai: info@tanocable.com

0.6/1 KV ABC –Aerial Bundled Cable- BS 7870-5 (AL/XLPE)

Aerial Bundled Cable BS 7870-5
No. of Core & Size	Phase Core				Neutral Core				Complete Cable
	No. & Section Area	No. of wire	Dia. of Conductor (Approx.)	Insulation Thickness	No. & Section Area	No. of Wire	Dia. of Conductor (Approx.)	Insulation Thickness	Overall Diameter (Approx.)	Weight (Approx.)
mm2	mm2	No.	mm	mm	mm2	No.	mm	mm	mm	kg/km
1x25	1x25	7	6.0	1.3	-	-	-	-	8.6	96
1x35	1x35	7	7.0	1.3	-	-	-	-	9.6	126
1x50	1x50	19	8.4	1.5	-	-	-	-	11.4	183
1x70	1x70	19	10.0	1.5	-	-	-	-	13.0	236
1x95	1x95	19	11.6	1.7	-	-	-	-	15.0	323
1x120	1x120	19	13.0	1.7	-	-	-	-	16.4	399
2x25	1x25	7	6.0	1.3	1x25	7	6.0	1.3	17.2	192
2x35	1x35	7	7.0	1.3	1x35	7	7.0	1.3	19.2	252
2x50	1x50	19	8.4	1.5	1x50	19	8.4	1.5	22.8	365
2x70	1x70	19	10.0	1.5	1x70	19	10.0	1.5	26.0	472
2x95	1x95	19	11.6	1.7	1x95	19	11.6	1.7	30.0	645
2x120	1x120	19	13.0	1.7	1x120	19	13.0	1.7	32.8	798
3x25	2x25	7	6.0	1.3	1x25	7	6.0	1.3	18.5	288
3x35	2x35	7	7.0	1.3	1x35	7	7.0	1.3	20.6	378
3x50	2x50	19	8.4	1.5	1x50	19	8.4	1.5	24.5	548
3x70	2x70	19	10.0	1.5	1x70	19	10.0	1.5	28.0	708
3x95	2x95	19	11.6	1.7	1x95	19	11.6	1.7	32.3	968
3x120	2x120	19	13.0	1.7	1x120	19	13.0	1.7	35.3	1196
4x25	3x25	7	6.0	1.3	1x25	7	6.0	1.3	20.7	384
4x35	3x35	7	7.0	1.3	1x35	7	7.0	1.3	23.1	504
4x50	3x50	19	8.4	1.5	1x50	19	8.4	1.5	27.5	731
4x70	3x70	19	10.0	1.5	1x70	19	10.0	1.5	31.4	943
4x95	3x95	19	11.6	1.7	1x95	19	11.6	1.7	36.2	1290
4x120	3x120	19	13.0	1.7	1x120	19	13.0	1.7	39.6	1595
5x25	4x25	7	6.0	1.3	1x25	7	6.0	1.3	23.2	480
5x35	4x35	7	7.0	1.3	1x35	7	7.0	1.3	25.9	630
5x50	4x50	19	8.4	1.5	1x50	19	8.4	1.5	30.8	914
5x70	4x70	19	10.0	1.5	1x70	19	10.0	1.5	35.1	1179
5x95	4x95	19	11.6	1.7	1x95	19	11.6	1.7	40.5	1613
5x120	4x120	19	13.0	1.7	1x120	19	13.0	1.7	44.3	1993

Our ABC aerial cable competitive price will send you within 12 hours. We can customize other cross-sections of aerial bundled cable on your request.

0.6/1 KV ABC –Aerial Bundled Cable- AS/NZS 3560.1

Aerial Bundled Cable AS/NZS 3560.1
No. of Core & Size	Phase Core				Neutral Core				Complete Cable
	No. & Section Area	No. of Wire	Dia. of Conductor (Approx.)	Insulation Thickness	No. & Section Area	No. of Wire	Dia. of Conductor (Approx.)	Insulation Thickness	Overall Dia. (Approx.)	Weight (Approx.)
mm2	mm2	No.	mm	mm	mm2	No.	mm	mm	mm	kg/km
2x16	1x16	7	4.7	1.3	1x16	7	4.7	1.3	14.6	132
4x16	3x16	7	4.7	1.3	1x16	7	4.7	1.3	17.6	263
2x25	1x25	7	6.0	1.3	1x25	7	6.0	1.3	17.2	189
3x25	2x25	7	6.0	1.3	1x25	7	6.0	1.3	18.5	283
4x25	3x25	7	6.0	1.3	1x25	7	6.0	1.3	20.8	378
2x35	1x35	7	7.0	1.3	1x35	7	7.0	1.3	19.2	249
3x35	2x35	7	7.0	1.3	1x35	7	7.0	1.3	20.7	373
4x35	3x35	7	7.0	1.3	1x35	7	7.0	1.3	23.2	497
2x50	1x50	7	8.1	1.5	1x50	7	8.1	1.5	22.2	334
3x50	2x50	7	8.1	1.5	1x50	7	8.1	1.5	23.9	501
4x50	3x50	7	8.1	1.5	1x50	7	8.1	1.5	26.8	668
4x70	3x70	19	10.0	1.5	1x70	19	10.0	1.5	31.4	933
2x95	1x95	19	11.6	1.7	1x95	19	11.6	1.7	30.0	638
4x95	3x95	19	11.6	1.7	1x95	19	11.6	1.7	36.2	1276
4x120	3x120	19	13.0	1.7	1x120	19	13.0	1.7	39.6	1579
4x150	3x150	19	14.6	1.7	1x150	19	14.6	1.7	43.5	1883

Our ABC aerial cable competitive price will send you within 12 hours. We can customize other cross-sections of aerial bundled cable on your request.

Aerial Bundled Cable NF C 33-209

Aerial Bundled Cable NF C 33-209
No. of Conductor and Cross Section Area	Phase Core				Neutral Core				Street Lighting Core				Complete Cable
	No. and Section Area	No. of Wire	Dia. of Conductor (Approx.)	Insulation Thickness	No. and Section Area	No. of Wire	Dia. of Conductor (Approx.)	Insulation Thickness	No. and Section area	No. of Wires	Diameter of conductor	Insulation Thickness	Overall Diameter (Approx.)	Weight (Approx.)
mm2	mm2	No.	mm	mm	mm2	No.	mm	mm	mm2	No.	mm	mm	mm	kg/km
2x16	2x16	7	4.8	1.2	-	-	-	-	-	-	-	-	14.2	126
2x25	2x25	7	6.0	1.4	-	-	-	-	-	-	-	-	17.6	194
2x35	2x35	7	7.0	1.6	-	-	-	-	-	-	-	-	20.4	266
2x50	2x50	7	8.1	1.6	-	-	-	-	-	-	-	-	22.6	341
4x16	4x16	7	4.8	1.2	-	-	-	-	-	-	-	-	17.2	252
4x25	4x25	7	6.0	1.4	-	-	-	-	-	-	-	-	21.2	388
4x35	4x35	7	7.0	1.6	-	-	-	-	-	-	-	-	24.6	533
3x25+54.6	3x25	7	6.0	1.4	1x54.6	7	9.45	1.6	-	-	-	-	23.6	496
3x25+54.6+1x16	3x25	7	6.0	1.4	1x54.6	7	9.45	1.6	1x16	7	4.8	1.2	24.9	560
3x25+54.6+2x16	3x25	7	6.0	1.4	1x54.6	7	9.45	1.6	2x16	7	4.8	1.2	26.6	624
3x35+54.6	3x35	7	7.0	1.6	1x54.6	7	9.45	1.6	-	-	-	-	26.1	604
3x35+54.6+1x16	3x35	7	7.0	1.6	1x54.6	7	9.45	1.6	1x16	7	4.8	1.2	27.2	668
3x35+54.6+2x16	3x35	7	7.0	1.6	1x54.6	7	9.45	1.6	2x16	7	4.8	1.2	28.7	732
3x50+54.6	3x50	7	8.1	1.6	1x54.6	7	9.45	1.6	-	-	-	-	28.1	716
3x50+54.6+1x16	3x50	7	8.1	1.6	1x54.6	7	9.45	1.6	1x16	7	4.8	1.2	28.9	780
3x50+54.6+2x16	3x50	7	8.1	1.6	1x54.6	7	9.45	1.6	2x16	7	4.8	1.2	30.3	844
3x70+54.6	3x70	12	10.0	1.8	1x54.6	7	9.45	1.6	-	-	-	-	32.2	940
3x70+54.6+1x16	3x70	12	10.0	1.8	1x54.6	7	9.45	1.6	1x16	7	4.8	1.2	32.7	1004
3x70+54.6+2x16	3x70	12	10.0	1.8	1x54.6	7	9.45	1.6	2x16	7	4.8	1.2	33.8	1068
3x70+54.6+1x25	3x70	12	10.0	1.8	1x54.6	7	9.45	1.6	1x25	7	6.0	1.4	33.6	1038
3x70+54.6+2x25	3x70	12	10.0	1.8	1x54.6	7	9.45	1.6	2x25	7	6.0	1.4	35.5	1137
3x70+70	3x70	12	10.0	1.8	1x70	7	10.20	1.5	-	-	-	-	32.1	970
3x70+70+1x16	3x70	12	10.0	1.8	1x70	7	10.20	1.5	1x16	7	4.8	1.2	32.5	1035
3x70+70+2x16	3x70	12	10.0	1.8	1x70	7	10.20	1.5	2x16	7	4.8	1.2	33.6	1099
3x95+70	3x95	19	11.7	1.8	1x70	7	10.20	1.5	-	-	-	-	35.6	1212
3x95+70+1x16	3x95	19	11.7	1.8	1x70	7	10.20	1.5	1x16	7	4.8	1.2	35.7	1276
3x95+70+2x16	3x95	19	11.7	1.8	1x70	7	10.20	1.5	2x16	7	4.8	1.2	36.6	1340
3x120+70	3x120	19	13.0	1.8	1x70	7	10.20	1.5	-	-	-	-	38.0	1439
3x120+70+1x16	3x120	19	13.0	1.8	1x70	7	10.20	1.5	1x16	7	4.8	1.2	37.8	1503
3x120+70+2x16	3x120	19	13.0	1.8	1x70	7	10.20	1.5	2x16	7	4.8	1.2	38.6	1567
3x150+70	3x150	19	14.4	1.7	1x70	7	10.20	1.5	-	-	-	-	40.2	1650
3x150+70+1x16	3x150	19	14.4	1.7	1x70	7	10.20	1.5	1x16	7	4.8	1.2	39.8	1714
3x150+70+2x16	3x150	19	14.4	1.7	1x70	7	10.20	1.5	2x16	7	4.8	1.2	40.4	1778
3x120+95	3x120	19	13.0	1.8	1x95	19	12.50	1.6	-	-	-	-	39.5	1526
3x120+95+1x16	3x120	19	13.0	1.8	1x95	19	12.50	1.6	1x16	7	4.8	1.2	39.5	1590
3x120+95+2x16	3x120	19	13.0	1.8	1x95	19	12.50	1.6	2x16	7	4.8	1.2	39.8	1654

Our ABC aerial cable competitive price will send you within 12 hours. We can customize other cross-sections of aerial bundled cable on your request.
